Cat6-6A Pass Through RJ45 Connectors | Shielded | 10pc | Conductors inserted

1/10

Description

Pass Through Design

No more load bars means less waste and frustration. The ability to see the conductors come through the front of the plug allows you to verify the correct TIA 568A or 568B color sequence which minimizes bad terminations.

Maximum Performance

Ensuring the best cable to plug combination, pass through plugs allow a push-pull method to seat the cable jacket as far into the plug as possible, minimizing crosstalk.
Triple prong gold plated contacts.
Staggered conductor design.
Shielded (External Ground) construction.
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) 4PPoE up to 100W.

Versatile

Compatible with 23AWG stranded or solid conductors.
Suitable for cable jacket diameters up to ∅8.00mm and conductor insulation diameters from ∅1.05 - 1.25mm.
Terminate with our All-In-One Crimp and Termination Tool.

Quality Guaranteed

ANSI/TIA 568 2.D Certified and Validated with trueCABLE F/UTP Ethernet cable. ETL, UL, SGS (RoHS REACH / SVHC) Verified and Tested. FCC compliant.

Resealable Bag

These shielded pass through RJ45 ends are sure to make your install hassle-free.

Item Details

Weight	0.1 lb
Length	6.25 in
Width	4.25 in
Height	0.50 in
Barcode	X002IWGSY1

Specs & User Guides

Download Spec Sheet

Cat6/6A Pass Through RJ45 Connectors｜Shielded

Part Number - LGEGPTRJ45_10pc

$19.99

Hassle free pass through design
Triple prong gold plated contacts
Supports PoE++ (802.3bt) 4PPoE, up to 100W
Terminate with our All-In-One Crimp and Termination Tool
UL Listed, ETL Verified, ANSI/TIA 568 2.D Certified

Visit the Product Certification and Compliance List for full documentation and technical standards.

Bulk Save with trueCABLE
Qty	Price Per Item	Your Savings
10-24	$19.49	2.5%
25-49	$18.99	5%
50+	$18.49	7.5%

Why buy direct from trueCABLE?

30 day returns Returns Policy

We stand by our products with our Forever Warranty

Same-day shipping on orders placed Mon-Fri by 3pm Central. Free shipping on all orders over $449.99.

Description

Pass Through Design

No more load bars means less waste and frustration. The ability to see the conductors come through the front of the plug allows you to verify the correct TIA 568A or 568B color sequence which minimizes bad terminations.

Maximum Performance

Ensuring the best cable to plug combination, pass through plugs allow a push-pull method to seat the cable jacket as far into the plug as possible, minimizing crosstalk.
Triple prong gold plated contacts.
Staggered conductor design.
Shielded (External Ground) construction.
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) 4PPoE up to 100W.

Versatile

Compatible with 23AWG stranded or solid conductors.
Suitable for cable jacket diameters up to ∅8.00mm and conductor insulation diameters from ∅1.05 - 1.25mm.
Terminate with our All-In-One Crimp and Termination Tool.

Quality Guaranteed

ANSI/TIA 568 2.D Certified and Validated with trueCABLE F/UTP Ethernet cable. ETL, UL, SGS (RoHS REACH / SVHC) Verified and Tested. FCC compliant.

Resealable Bag

These shielded pass through RJ45 ends are sure to make your install hassle-free.

Specifications

Weight	0.1 lb
Length	6.25 in
Width	4.25 in
Height	0.50 in
Barcode	X002IWGSY1

Downloads

Download Spec Sheet

Frequently Asked Questions

Are there any tools or kits available for terminating these connectors?

Yes, we offer an All-In-One Crimp and Termination Tool specifically designed for terminating trueCABLE's Cat6/6A Pass Through RJ45 Connectors, making the installation process efficient and hassle-free.

Are these connectors UL Listed, ETL Verified, and ANSI/TIA 568 2.D Certified?

Yes, our Cat6/6A Pass Through RJ45 Connectors meet or exceed various industry standards, including UL Listing, ETL Verification, and TIA/EIA certifications for safety and performance.

Are these connectors compatible with PoE++ devices?

Yes, they support PoE++ (802.3bt) 4PPoE, up to 100W, making them suitable for applications requiring high-power over Ethernet.

Are these RJ45 connectors shielded or unshielded?

These pass-through RJ45 connectors are shielded, which helps reduce electromagnetic interference (EMI) and crosstalk, ensuring reliable data transfer over longer distances.
