Cat5e Pass Through RJ45 Connectors | Shielded | 20pc | Conductors Inserted

1/10

Description

Pass Through Design

No more load bars means less waste and frustration. The ability to see the conductors come through the front of the plug allows you to verify the correct TIA 568A or 568B color sequence which minimizes bad terminations.

Maximum Performance

Ensuring the best cable to plug combination, pass through plugs allow a push-pull method to seat the cable jacket as far into the plug as possible.
Triple prong gold plated contacts.
Shielded (Internal Ground) construction.
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) 4PPoE up to 100W.

Versatile

Compatible with 23 and 24AWG stranded or solid conductors.
Suitable for cable jacket diameters up to ∅7.00mm and conductor insulation diameters from ∅0.85 - 1.05mm.
Terminate with our All-In-One Crimp and Termination Tool.

Quality Guaranteed

ANSI/TIA 568 2.D Certified and Validated with trueCABLE F/UTP Ethernet cable. ETL, UL, SGS (RoHS REACH / SVHC) Verified and Tested. FCC compliant.

Resealable Bag

These shielded pass through RJ45 ends are sure to make your install hassle-free.

Item Details

Weight	0.14 lb
Length	6.25 in
Width	4.25 in
Height	0.50 in
Barcode	X002IW95R3

Specs & User Guides

Download Spec Sheet

Cat5e Pass Through RJ45 Connectors｜Shielded

Part Number - SMIGPTRJ45_20pc

$22.99

Hassle free pass through design
Triple prong gold plated contacts
Supports PoE++ (802.3bt) 4PPoE, up to 100W
Terminate with our All-In-One Crimp and Termination Tool
UL Listed, ETL Verified, ANSI/TIA 568 2.D Certified

Visit the Product Certification and Compliance List for full documentation and technical standards.

Bulk Save with trueCABLE
Qty	Price Per Item	Your Savings
10-24	$22.42	2.5%
25-49	$21.84	5%
50+	$21.27	7.5%

Why buy direct from trueCABLE?

30 day returns Returns Policy

We stand by our products with our Forever Warranty

Same-day shipping on orders placed Mon-Fri by 3pm Central. Free shipping on all orders over $449.99.

Description

Pass Through Design

No more load bars means less waste and frustration. The ability to see the conductors come through the front of the plug allows you to verify the correct TIA 568A or 568B color sequence which minimizes bad terminations.

Maximum Performance

Ensuring the best cable to plug combination, pass through plugs allow a push-pull method to seat the cable jacket as far into the plug as possible.
Triple prong gold plated contacts.
Shielded (Internal Ground) construction.
Supports Power over Ethernet: PoE/PoE+/PoE++ (IEEE 802.3af/at/bt) 4PPoE up to 100W.

Versatile

Compatible with 23 and 24AWG stranded or solid conductors.
Suitable for cable jacket diameters up to ∅7.00mm and conductor insulation diameters from ∅0.85 - 1.05mm.
Terminate with our All-In-One Crimp and Termination Tool.

Quality Guaranteed

ANSI/TIA 568 2.D Certified and Validated with trueCABLE F/UTP Ethernet cable. ETL, UL, SGS (RoHS REACH / SVHC) Verified and Tested. FCC compliant.

Resealable Bag

These shielded pass through RJ45 ends are sure to make your install hassle-free.

Specifications

Weight	0.14 lb
Length	6.25 in
Width	4.25 in
Height	0.50 in
Barcode	X002IW95R3

Downloads

Download Spec Sheet

Frequently Asked Questions

What type of connectors are these Cat5e pass through RJ45 connectors?

This is a shielded pass-through RJ45 connector, designed for use with shielded Ethernet cables, and specifically tested for compatibility with all trueCABLE shielded Cat5e bulk Ethernet cable.

Do these connectors support PoE++ (802.3bt)?

This RJ45 connector supports IEEE 802.3af/at/bt (PoE/PoE+/PoE++) standards and can handle 4PPoE up to 100W DC, making it suitable for powering devices with high power requirements.

Are these connectors UL Listed and ETL Verified?

Yes, this product is UL Listed, cETLus Verified, and IEEE 802.3 Compliant.

Can I use these connectors in both indoor and outdoor installations?

These RJ45 connectors are designed for indoor use and should be protected from exposure to the elements when installed outdoors.
