What Is CMX Cable? Understanding the Fire Rating, and Common Misconceptions

Written by Don Schultz, trueCABLE Senior Technical Marketing Specialist, BICSI TECH, INSTC, INSTF, Fluke Networks Copper/Fiber CCTT Certified

In the structured cabling industry, an often misused term is CMX. It's slapped on labels, spec sheets, and marketing materials — often with good intentions but is it technically accurate? In this article, we’re clearing the air on what CMX cable actually is — and what it’s not.

Whether you're an installer, engineer, distributor, or product manager, understanding the real meaning of CMX can help you stay compliant, avoid liability, and make better cabling choices for your customers.

In the cabling and connectivity industry, clear definitions matter — especially when it comes to safety ratings. While it's often misunderstood or misused, CMX is a clearly defined fire safety rating governed by UL standards and recognized by the National Electrical Code (NEC®).

We are going to clarify:

• What makes a cable CMX-rated, according to UL standards
• How the NEC (NFPA 70) defines and regulates the use of CMX
• Common industry misconceptions, like CMX \= outdoor
• What the VW-1 vertical flame test involves — and why it matters
• Whether there is such a thing as an outdoor CMX cable
• If outdoor cable (OSP or outside plant) needs a CMX rating (hint: not always)
• The risks and liabilities of labeling a cable as CMX when it hasn’t been tested

This is critically important, as you might end up with counterfeit cable without realizing it!

What makes a cable CMX fire rated, according to UL standards?

CMX cable is a type of communications cable that has been tested and certified to meet the CMX fire-resistance rating, as defined by UL-444 and referenced in the National Electrical Code® (NEC®). It is designed for residential applications, typically within one and two family dwellings (duplex dwellings), and is intended for use in limited indoor installations where minimal fire resistance is acceptable.

The CMX fire rating denotes “Communications, Limited Use”

To be classified as CMX, a cable must pass the Vertical Wire Flame Test (VW-1), as specified in UL 1581, Section 1080, which ensures the cable can self-extinguish and limit flame propagation when subjected to a direct flame.

This is the lowest level of fire protection among communication cable ratings (compared to CM, CMR, and CMP). A compliant CMX cable must also be listed and labeled by an accredited testing body such as UL or ETL.

To see more on what CM, CMG, CMR, and CMP means, please refer to Facts About Ethernet Cable Jacket Ratings.

While CMX cables may sometimes have durable outdoor-rated jackets (e.g., LLDPE), this jacket material does not determine the CMX rating; the designation applies strictly to the cable’s fire performance, not its environmental durability. Properly rated CMX cables are permitted in short runs (typically under 50 feet) when entering a residence, or in exposed indoor applications where higher fire ratings are not required.

So to recap to be officially CMX-rated, a cable must meet the following key requirements:

• Pass the VW-1 Vertical Flame Test (as defined in UL 1581, Section 1080)
• Be listed and labeled by a recognized certification body such as UL or ETL
• Intended for use in one or two family dwellings and limited indoor runs (typically up to 50 feet inside the building)
• Not approved for use in riser or plenum spaces

How the NEC (NFPA 70) defines and regulates the use of CMX

The National Electrical Code (NEC) also known as NFPA 70, governs the installation of electrical and communications wiring in the U.S. CMX cable is explicitly referenced in NEC 2023, Article 800.113, which lays out the following:

• CMX cables, by definition, are considered Listed for limited residential use (UL, ETL, etc.)
• In one and two family dwellings, CMX is permitted in general applications if the cable is ≤ 0.25″ in diameter, otherwise the cable must be treated as Unlisted even for residential use and must obey commercial rules as specified below
• In commercial structures, CMX is considered Unlisted and is not suitable for use inside of the structure with the exception that the cable may come in from outside up to a maximum of 50 feet before termination or transition to an acceptable indoor fire rated cable

Yes, you heard that right! For commercial purposes in the USA, CMX fire rated cable is considered to be completely Unlisted as if it had no fire rating at all.

How ETL and UL Defines and Regulates CMX Cables

UL (Underwriters Laboratories) and ETL (Intertek’s Electrical Testing Labs) are both Nationally Recognized Testing Laboratories (NRTLs) authorized by OSHA to test and certify electrical and communication products, including cables. When it comes to CMX cable, both UL and ETL follow the same testing criteria set forth in UL-444 and UL-1581, which are the key standards for communications cable construction and fire performance.

So how does UL and ETL define CMX cable? CMX is defined as the lowest level of flame resistance for communication cables. It is intended for residential installations with limited flame-spread risk.

CMX-rated cables must be clearly labeled with the marking “CMX” and bear the certifying lab’s listing mark (e.g., “UL Listed” or “ETL Verified”).

Product Submission: The manufacturer submits a complete cable sample to UL or ETL for evaluation.

Lab Testing: The lab performs physical construction verification and the VW-1 flame test.

What Is the VW-1 Vertical Flame Test?

The VW-1 test (UL 1581, Section 1080) involves applying a flame directly to a vertically mounted cable for a specific duration.

Testing Requirements: To qualify as CMX-rated, the cable must pass the following:

Flame Duration: The flame application time is 75 seconds total, performed as 5 separate applications of 15 seconds each.

• A 20 mm flame is applied vertically to a one-meter cable sample five times.
• The flame must not propagate more than 24 inches (60 cm).
• The cable must self-extinguish quickly after the flame is removed.

The test ensures the cable won’t support flame spread if ignited. If a cable fails this test, it cannot be labeled CMX, regardless of its outer jacket material.

Compliance Verification: If the cable passes, the lab certifies the product and issues a listing number.

Labeling and Marking: The cable is authorized to carry the CMX rating and listing mark (e.g., UL or ETL logo).

Ongoing Surveillance: Certified manufacturers are subject to periodic factory inspections to ensure continued compliance and no material substitution.

Why This Matters:

A cable cannot legally be called CMX unless it has been:

• Tested to UL 1581 flame criteria
• Evaluated for compliance with UL-444
• Listed and labeled by UL or ETL

Industry Misinterpretations: CMX ≠ Outdoor

One of the most common misconceptions in the cabling industry is that “CMX” means outdoor cable. This is incorrect.

Here’s why:

• CMX is a fire rating, not an environmental or durability rating.
• Many cables marketed as “Outdoor CMX” use LLDPE (Linear Low-Density Polyethylene) jackets, which are great for UV and moisture resistance, but often have nothing to do with fire resistance and typically cannot achieve a CMX fire rating
• LLDPE jackets do not inherently pass the CMX (VW-1) flame test and unless the cable has been tested and certified, it should not be labeled CMX

By definition, any cable that does not meet the fire rating requirements, nor proceed through the testing and validation process, yet receives a marking such as “CMX” on the cable jacket is absolutely counterfeit cable.

In industry-speak, outdoor cable is referred to as “OSP” or Outside Plant. Usually OSP is considered to be Unlisted and treated as such. This is especially true in the commercial space where there are no exceptions or caveats.

Is There an Outdoor CMX-Rated Cable?

Yes, but there’s a difference. An outdoor cable isn’t the same as a CMX-rated cable. This distinction is important to understand when you see these two terms printed on a cable. What are some of the differences when evaluating a cable that is outdoor rated vs CMX rated.

There are cables that:

• Use LLDPE jackets for outdoor durability (but typically HDPE instead of LLDPE)
• Have also passed the VW-1 flame test
• Are properly tested and listed as CMX

In those cases, you might see the label “Outdoor CMX,” but it’s critical to understand this means:

• The LLDPE jacket provides outdoor protection
• The CMX rating applies only to the fire performance of the cable
• The cable has been properly tested and certified, assuming the cable in question passed the flame testing and was properly submitted and assigned a Listed via the NRTL

So yes, Outdoor CMX can exist, but only if the cable is both outdoor-rated and CMX fire rated and not all LLDPE jacketed cables meet both criteria. Often, LLDPE cable jackets will cause significant issues with achieving the necessary flame test performance to achieve a CMX rating. HDPE is often used instead for these cable types that are meant for outdoor use yet have a legitimate CMX fire rating.

Does Outdoor Cable Need a CMX Rating?

No, not if it’s used entirely outdoors. Cabling without a fire rating is legally considered Unlisted and much OSP cable fits into this category.

Cables used solely outdoors (e.g., buried in conduit or aerial runs) are generally not required to meet any fire safety rating such as CMX, CMR, or CMP.

In commercial situations, even Unlisted cable coming from outdoors to indoors may ingress 50 feet before it must be terminated or transitioned to an acceptable indoor fire rated cable.

The Risk of Mislabeling: What Happens When a Cable Is Called “CMX” But Isn’t?

Mislabeling a cable as “CMX” when it hasn’t been tested and certified can have serious consequences:

• Violates NEC and local building codes
• Invalidates product safety listings.
• Exposes contractors and manufacturers to potential legal and insurance liability.
• Puts end users at risk in the event of a fire.

The cable rating indicates the cable is designed for specific environments, the VW-1 flame test ensures it can withstand fire exposure without contributing to the spread of flames based on that specific criteria, much like how a crash test ensures a safety seat can protect a child in a collision.

Just as you wouldn’t rely on a seat labeled “safe” without proof of rigorous testing, you shouldn’t trust a cable’s fire rating without confirmation it has passed the required testing. This verification is critical to ensuring safety and reliability in real-world conditions.

Conclusion

CMX is a specific fire rating, not a general-purpose label for outdoor cables. It plays an important role in meeting NEC requirements for residential communication cabling. But its meaning and limitations are often misunderstood.

To use CMX cable correctly:

• Understand that it refers to fire performance, not weather resistance

• Use certified and tested CMX cables only where NEC allows

• Don’t assume outdoor-rated equals CMX — and don’t label LLDPE-jacketed cables as CMX unless they've passed the required flame test

When in doubt, always refer to UL listings, ETL certifications, and the NEC codebook, and avoid relying on marketing terms alone.

Happy Networking!
