How to: Terminate an Unshielded Punch Down Keystone Jack

How to: Terminate an Unshielded Punch Down Keystone Jack

Written by Don Schultz, Technical Sales Representative and Fluke Networks Certified Technician

Options are a good thing to have at your disposal. When terminating Ethernet cable, there are a number of ways such as with RJ45 plugs, patch panels, and keystone jacks. We will be focusing on a certain type of keystone jack for this blog, and it is “old school”. Meet the punch down keystone jack. Don’t let the “old school” moniker fool you. The punch down keystone jack, generally speaking, remains extremely effective and costs less per jack than the toolless types.

Keystone jacks help to avoid “spaghetti monster” cable installations. When used as intended, keystone jacks become your secret weapon to help avoid this, allowing you to install a “permanent link”. How do I get one of those, you may ask? Well, you will definitely need an Ethernet keystone jack to pull it off! The other end of the permanent link will be yet another keystone jack or a patch panel. For the DIY installer, this might be a new concept. Many first time installers will put RJ45 connector plugs onto both ends of the cable. Now, this will work, but it will restrict your installation in one key way: flexibility. It is also the potential birth of the “spaghetti monster”. Another item worth mentioning is that permanent links change up permitted lengths. You get more flexibility, but there are a few more rules to be aware of as outlined in Maximum Ethernet Cable Length.

The downside to punch down keystone jacks is they require an additional tool specifically designed to terminate them. The most common tool used is the 110 type kinetic energy punch down tool such as the one trueCABLE sells, our trueIMPACT. This method is time tested, but also potentially time consuming!

The trueTERM EZ termination tool is the best option for those that install gobs of punch down keystone jacks. This tool makes the process faster and more accurate.

This blog is a companion to the video below. I strongly recommend you watch the video and read the blog. Both mediums bring something to the table.



This blog focuses on our punch down Cat5e unshielded keystone jack. These instructions are suitable for any of our unshielded punch down keystone jacks, regardless of Category. Just be aware that Cat5e cable does not have a center spline, and both Cat6 and Cat6A will require spline removal.

Here are the tools you will need or want:

Required cable preparation tools:

 For cable stripping and preparation...

For cable stripping and preparation...



Required termination tool (either / or):

Either of these tools will work

Either of these tools will work



For this demonstration I am using our Cat5e Unshielded Plenum cable.



First, let’s talk about the anatomy of the punch down keystone jack:

 Both sides of the jack housing, showing off the T568A and B color code schemes

Both sides of the jack housing, showing off the T568A and B color code schemes.



Pointed IDC towers, outlined in red, which allow for conductor pair separation.  You can also just make out the actual metal contacts at the bottoms of the IDC slots.

Pointed IDC towers, outlined in red, which allow for conductor pair separation. You can also just make out the actual metal contacts at the bottoms of the IDC slots.

  • The pointed IDC (insulation-displacement contact) tower make getting tight terminations easy, without the need to untwist the pair
  • The closer the last twist in the conductor pair is to the actual IDC contact, the better the termination will operate
  • The ANSI/TIA 568 defined maximum conductor pair untwist is 0.50”. This means to remain in specification, the distance from the last twist in the pair to the point of electrical contact cannot exceed 0.50”.



Let’s get to it!

You want to score it, not cut through it.  Then, pop open the jacket by bending a couple of times at the score.

Start by stripping off about 2 ½” of cable jacket. You want to score it, not cut through it. Then, pop open the jacket by bending a couple of times at the score.



Don’t underestimate the importance of checking for conductor nicks at the jacket edge!

Cut off the rip cord and inspect for conductor nicks. Don’t underestimate the importance of checking for conductor nicks at the jacket edge!



If you accidentally nicked a conductor, you will need to start over.  See What Does a Bad Termination Look Like? for pictures of what to look out for.

Orient the conductor pairs so they line up with the chosen T568A or B color code scheme.  We are using T568B for this demonstration.

Orient the conductor pairs so they line up with the chosen T568A or B color code scheme. We are using T568B for this demonstration.



It does not matter whether you use the T568A or T568B color coding scheme.   One is not better than the other. Just be sure to use the same color at both ends of the cable run!

  Do not place any part of the cable jacket into the jack housing.  Doing so will make proper termination difficult or impossible.

Do not place any part of the cable jacket into the jack housing. Doing so will make proper termination difficult or impossible.



Conductor pairs threaded into IDC channels

Conductor pairs threaded into IDC channels

  • Thread one pair at a time
  • Always start with the pairs closest to the RJ45 port on the jack
  • Use the pointed IDC towers to separate the the conductor pairs
  • Only untwist if the pairs will not line up properly on the IDC slots
  • Use the least amount of untwist necessary

 For 110 tool impact punch down, punch all eight wires fully into their IDC slots

For 110 tool impact punch down, punch all eight wires fully into their IDC slots

  • Our punch down keystone jacks only accept 110 tool blades
  • The cutting edge of the blade should be outside the jack housing
  • Punch downward straight and level as possible for best results
  • A second punch may be required to fully seat and/or flush cut the conductor
  • Set the impact tool to “HI” for 23 AWG conductors.  Set to “LO” for 24 AWG conductors.

ALTERNATIVELY:

The EZ termination tool makes this simple.  Place the pre-threaded jack in the tool, and operate the handle.  All conductors should be seated and cut in one operation.

The EZ termination tool makes this simple. Place the pre-threaded jack in the tool, and operate the handle.  All conductors should be seated and cut in one operation.



The conductors should be fully seated in the IDC channels and flush cut off. Snap on the IDC cap and done!

Inspect your work. The conductors should be fully seated in the IDC channels and flush cut off. Snap on the IDC cap and done! All ready to insert into a wall plate or keystone jack patch panel



Well, there you have it. A ready to go keystone jack termination. Now you can plug a patch cable into the RJ45 port on the jack and gain a degree of flexibility you may not have had previously.

HAPPY NETWORKING!!

WAIT!  Something went wrong?  Check out What Does a Bad Termination Look Like?
