Written by Don Schultz, trueCABLE Senior Technical Advisor, Fluke Networks Copper/Fiber CCTT, BICSI INST1, INSTC, INSTF Certified

Field termination plugs are a key way of achieving good performance when you need a male plug end as opposed to using a plain RJ45. I strongly recommend you use them when you can, and leave the RJ45s to pre-terminated patch cables that come from a factory. If you need to make a high performing custom and reliable patch cord (male to male end) in the field, especially when using solid copper Ethernet, you will need to use field termination plugs at both ends.

This is especially true when dealing with 10G speeds at Cat6A’s operating bandwidth of 500 MHz.

Advantages of field termination plugs:

  • Easy to terminate, even for a novice
  • Don’t require a special termination tool
  • Not fitment critical (RJ45s are super critical about fitment to the cable)
  • Reusable up to 20X. RJ45 8P8C connectors, once terminated, cannot be removed.
  • Provide maximum performance due to impedance matching and the Component rated PCB inside, which greatly reduces internal pair-to-pair cross talk

Disadvantages of field termination plugs:

  • Usually far more expensive than RJ45 8P8C plugs
  • Twice the length or more compared to RJ45 8P8C plugs, making their use in tight spaces not feasible (like outdoor WiFi AP housings, sealed IP camera housings, etc.)

Much has been written and said about Cat6A cable itself, but what does not get discussed nearly enough is the correct way to terminate your Cat6A Ethernet cable so that it will actually achieve 10GBASE-T. To be more correct, proper termination technique and accessories not only applies to 10G over Cat6A, but any Category cable at any speed. 10G just happens to be the most sensitive about the whole thing. Take a look at Choosing the Right Termination - Keystone Jack vs RJ45 Connector vs Field Termination Plug to find out the best to least best way to terminate Ethernet network cable. Apart from the equipment you will require to get there, the cabling and accessories beg that you pay attention to what you are doing! Although you can use Cat6 to achieve 10 Gigabit when going short distances, if you wish to get that speed all the way out to 328 feet you will need Category 6A Ethernet cable. Cat6A also provides the best future proofing that you can get short of fiber optic.

This is all well and good to know, but up until now finding an unshielded field termination plug has been next to impossible. Adding to the pain, if you wished to use a field termination plug on unshielded Ethernet you would need to use a shielded field termination plug and these are much more expensive than plain RJ45 8P8C plugs. This effectively put everyone into a “Catch-22” situation, which had to change.

The Solution


Cat6a unshielded field term plug
dimensions of cat6a unshielded field term plug


Our new Cat6A Unshielded Field Termination Plug

The companion video below is meant to be watched in context of reading this blog too. Please take a moment to watch how to work with this field termination plug and then we will get into high resolution photos and point out details and “gotcha” points.


Primary features of our new field termination plug:

  • Category 6A Certified, Component rated
  • Impedance matching
  • Backwards compatible with Cat6 and Cat5e, assuming the cable jacket OD is 6.00mm to 8.50mm
  • Compatible with 0.80mm to 1.22mm insulated conductors, 23 & 24AWG solid or stranded copper
  • Compatible with U/UTP Ethernet (unshielded)
  • PoE Certified for 802.3af/at/bt PoE/PoE+/PoE++ up to 90W DC
  • Tested with a Fluke DSX-8000 with trueCABLE Cat6A unshielded Ethernet cable for TIA 568-2.D, Cat6A MPTL +PoE and TIA 568-2.D Cat6A Patch Cord performance
  • 3-way cable attachment (from bottom or top vertical to the plug housing or straight-in)

Termination Steps & Details to Know

cable cutter in action

Strip off about 1.5” of cable jacket. Be careful not to nick conductors during the stripping process!

Remove cable spline

Remove cable spline

tipsDon’t cut the spline straight across. Cut each wing (four of them) at a downward angle towards the cable jacket and then twist to remove.

Wire up the conductor holder cap rear pairs first. T568B sequence shown.

Wire up the conductor holder cap rear pairs first. T568B sequence shown.


  1. Make sure the cable jacket is snug against the stop point
  2. Secure the rear pairs first to keep the cable jacket snug


 cat6a unshielded field term plug, Front pairs inserted into slots

Front pairs inserted into slots

cat6a unshielded field term plug, Flush cut off conductor excess

Flush cut off conductor excess

cat6a unshielded field term plug, Insert conductor holder cap into field term plug body

Insert conductor holder cap into field term plug body


Insert the conductor holder cap under the clear locking latch and mate up the rectangular slot in the conductor holder cap with the blue rectangular post in the field termination plug body. Then press down.

Press and snap the conductor holder cap so the white tabs (two each side) are engaged

Press and snap the conductor holder cap so the white tabs (two each side) are engaged


cat6a unshielded field term plug

Often the thick insulated conductors of Cat6A Ethernet cable will pose a significant issue for people without the finger strength to snap the plug together. In this case, use our Parallel Jaw Pliers (PN: trueCLOSE).

cat6a unshielded field term plug

The final step is to apply the zip tie.  Three positions are possible.

There you have it. Our Cat6A Unshielded 3-Way Field Termination Plug will allow you to create high quality, high speed, and reliable in-field custom made patch cords for connections that really matter! See, you really can “have it your way”.
